ITEM
|
SPECIFICATION
|
| Normal capacity | 2500 mAh EC |
| Minimum capacity | 2450 mAh@0.5C
(Discharge the cell from 4.2V to 2.75V by 0.5C current) |
| Normal voltage | 3.6V |
| Charging voltage | 4.2 ±0.05 V |
| Discharge ending voltage | 2.75 ±0.05 V |
| Standard charging current | 0.5C(1250mA) |
| Standard discharge current | 1C(2500mA) |
| Max charge current | 1C(T≥10℃)
0.5C(10℃>T≥0℃) |
| Max continuous discharge current | 3C(27℃≥T≥23℃) |
| Max pulse discharge current | 5C(27℃≥T≥23℃) |
| Max recommended charge and discharge cell body temperature | Charge:0~ 45℃
Discharge:-20~ 60℃ |
| Maximum short term allowable charge and discharge cell body temperature. Charging and discharging at these conditions will shorten
cell cycle life. |
Charge: 60℃
Discharge: 75℃
|
| Internal resistance | ≤20mΩ(AC Impedance, 1000 Hz) |
| Cell dimension | Height : 65.1 mm Max
Diameter :18.4mm Max |
| Weight | ≤ 48g |
Application:
Flashlight, electric tools, electric bicycles, electric vehicles, electronic cigarette.Electric toys, electric shavers, electronic lamp, emergency lights, beacon light, etc.
Certification:
Cooperative paretner:
FAQ:
Q1: What about the quality of your battery?
A: We only produce safe, reliable and longetive battery, all products have passed the CE, RoHS certifications.
Q2: How to solve the technical problem?
A: 24 hours after-service consultancy just for you. If you meet any problem, please don't hesitate to contact us.
Q3: Can I have a sample order for battery?
A: Yes, we welcome sample order to test and check quality, samples are free. Mixed samples are acceptable.
Q4: Can I print my own logo on the product?
A: Yes, we welcome OEM and ODM orders. Please inform us formally before our production and confirm the design firstly based on our sample.
Q5: Do you have MOQ for your batteries?
A: OEM orders MOQ is 10,000 pcs. We can also accept small quantity for neutral orders.
